Paint Pack Cartridge Filter System
The innovative Paint Pack Cartridge filter system is an enclosed cartridge filter unit within a sealed outer bag. Whilst it is most commonly used in the paint industry, it is suitable for many applications which desire an enclosed, ready to use unit for reasons of user safety, cleanliness, hygiene and toxicity.
The system consists of a polypropylene adaptor with manifold, inlet and outlet ports and a double layered protective bag with filter cartridges located inside. Due to the protective bag, the liquid being filtered does not come into contact with the housing and protects the user from direct contact with the fluid during filter changeout.
The Paint Pack Cartridge filter system is manufactured with 1,3 or 7 filter cartridges and in lengths of 5” to 30” and can be equipped with different types of cartridges in accordance with suitability to the application.
[wpex more=”Read more” less=”Read less”]
- Adaptor : Polypropylene.
- Protective bag : Polyethylene or Nylon.
- Filter media: CP2 Two zone Polypropylene Depth filter or CP Polypropylene/Polyethylene nominal depth filter.
- Maximum temperature 60oC
- Maximum Differential Pressure: 3 Bar at 20oC
Please contact us for further information or view our range of Filter Cartridges.
LV1 Stainless Steel Single Cartridge Housings
The LV1 series single cartridge vessels consist of an investment cast head with 1” BSP (F) inline connections and 1/8” BSP (F) vent, a quick release clamp, and a bowl with ¼” BSP (F) bottom drain. LV1 vessels are produced in four sizes to suit industry standard 10”, 20”, 30” and 40” nominal length filter cartridges. The universal head can be configured to suit double open ended, code 8 (222 o rings/fin) or code 3 (222 o rings / flat) cartridges.
Multi Round Stainless Steel Cartridge Housings
Multi round cartridge vessels feature a universal bottom cup to suit double open ended, code 8 (222 o rings/fin) or code 3 (222 o rings / flat) cartridges. Our vessel design therefore provides versatility – by simply exchanging the cartridge top sealing components, the vessel can be converted to suit either double open ended cartridges or to suit code 3 and 8 cartridges. For use with double open ended cartridges, vessels are provided with a cup and spring component which achieves both top sealing and cartridge core location, and a compression plate.
Plastic Cartridge Housings
Plastic Housings – For applications involving non-aggressive fluids, these are a low cost, small sized single cartridge housings to suit 10″ or 20″ cartridges. They consist of a polypropylene body and screw on lid which forms a leak proof seal by compression of an o ring. The body can either be opaque or clear. 1/2″ – 1 1/2″ BSP screwed inline connections are available as standard. An optional pressure release button is available on the inlet port. Available accessories include spanners and mounting brackets.
